BIONET – Low Salt Electrolysis + Ionization Copper and Silver – SUGAR VALLEY spécial

Description

BIONET uses two disinfection methods for perfect water sterilisation: salt electrolysis (>3 gr / l) to generate residual chlorine in the pool and the ionisation of copper and silver (algaecide, bactericide and flocculant) to generate a residual disinfectant in the pool.

Components:
– Electronic box
– Titanium cell with transparent PVC support 63 mm Ø

BIO 16 model:
Private pool up to 28°C: 65 m³
Private pool after 28°C: 40 m³

Model BIO 22:
Private swimming pool up to 28°C: 100 m³
Private swimming pool after 28°C: 80 m³

Model BIO 33:
Private swimming pool up to 28°C: 200 m³
Private pool after 28°C: 125 m³

Sugar Valley Optional Accessories Not Included

Redox Control Probe Kit for PSalt
Includes: Redox Meter, Redox Probe, Probe Holder

Glass pH Control Probe Kit (acid)
Includes: Electronic chip, 1 crystal pH probe, Complete bypass with keys, Probe holder with measuring cup, 3 meters of hose, Calibration solutions.

Redox Control Glass Probe Kit
Includes: Electronic chip, 1 crystal redox probe, 1 bypass probe holder with keys, Probe holder with measuring cup, 3 metres of hose, Filter for probe, Calibration solutions.

pH and redox control glass probe kit
Inlcui: Electronic chips,1 redox probe and 1 pH crystal probe, 2 bypass probe holders with keys, 3 metres of hose, Filter for probe, Calibration solutions.

Free chlorine control
Measurement and control in ppm’s of free chlorine in water. Start-up and shut-down control for saline electrolysis.

Includes: 1 free chlorine meter, 1 amperometric probe, 1 transparent rotameter,

Salinity control
Measurement and control of water conductivity. 1 220 V outlet with motorised opening/closing valve for purging or salt dosing.

Flow detector
Mechanical safety flow detector to stop the electrolysis due to lack of water flow.

Includes:1 special double connector,1 electronic circuit

Temperature Module
Active temperature probe, temperature filtration control, intelligent mode.

Includes:1 ½ » temperature probe, 1 probe holder

Wi-Fi Module
Sends data from the serial port over WiFi (for installations with on-site filtration technical coverage)

Includes:1 WiFi module, 2m cable, WIFI Antenna, 1 charger

Wall Mount
Surface mount for remote display placement.

Touch Screen Display

Electromagnetic pump 5 litres/hour

Electromagnetic pump suitable for metering larger volumes of chemicals.

Documentation

INSTRUCTION MANUAL – ES

TECHNICAL SHEET – ES

INSTRUCTION MANUAL – EN

TECHNICAL SHEET – EN
