Description
Description: The INVERX X20 JUMBO range of heat pumps offers the perfect balance between Turbo performance of up to 120 per cent and silent operation.
Equipped as standard with TurboSilence® technology, Fairland’s INVERX X20 JUMBO pumps have the lowest consumption on the market for the heat capacity supplied to the pool in the public pool range.
Turbo mode
120% heating capacity, heat the pool to the desired temperature in less time
Smart mode
20-100% heating capacity, intelligent maintenance of pool temperature and implementation of corresponding optimum heating capacity
Silent mode
20-60% heating capacity with low speed operation and low vibration without noise
HIGHLIGHTS:
– Remote control via Wi-Fi.
– Real-time consumption display.
– All-season operation from -20 °C to 43 °C.
– Longer life by working at a lower speed.
– Environmentally friendly R32 gas.
– Includes cover and sinoblocs.
Warranty
2 years warranty
Technical features
| Model | JBR150T | JBR300T |
| Maximum pool volume (m3) | 130-260 | 260-520 |
| Average water flow (m3/h) | 20-25 | 30-40 |
| Hydraulic connection | Ø 75 mm | Ø 90 mm |
| Power supply | 400 V / 3 / 50 Hz | 400 V / 3 / 50 Hz |
| Nominal absorbed power (A) | 2.02 a 13.5 | 3.75 a 25.4 |
| Dimensions (mm) | 1.545 x 458 x 1.630 | 2.108 x 640 x 2.040 |
| Coolant gas | R32 | R32 |
| Sound pressure (dB(A)) at 10m | 22.1~34.4 | 23.3~38.5 |
| Weight (kg) | 217 | 476 |
PERFORMANCE CONDITIONS: AIR AT 26 °C / WATER AT 26 °C / HYGRO 80%
| Power supplied (kW) | 60 | 120 |
| COP | 15.0~6.5 | 15.1~6.5 |
PERFORMANCE CONDITIONS: AIR AT 15 °C / WATER AT 26 °C / HYGRO 70%
| Power supplied (kW) | 42 | 82 |
| Absorbed power (kW) | 1.4~8.94 | 2.6~17.1 |
| COP | 8.0~4.8 | 7.5~4.8 |
