Description
The only commercial grade filter with a built-in pressure regulator for low volume irrigation zones. Also available with a clean/dirty status indicator.
Features
- Reduces maintenance and labour costs – 40% larger filter surface than standard filters results in less frequent cleaning
- Provides greater reliability – « no spillage » function ensures that dirt does not fall back into the filter during cleaning operation
- Simplifies installation and maintenance – o-ring threaded top makes removal and cleaning easier compared to stainless steel mesh filter
- Efficient design – combines filtration and pressure regulation in one compact unit with fewer connections
- Available in 1″ models
- Comes pre-assembled with 200 mesh (75 micron) stainless steel mesh filter (other mesh sizes available)
- Built-in 40 psi (2.7 bar) pressure regulator
Specifications
Operating Range
- Flow Rate: 5.0 to 20 gpm (18.9 to 75.7 l/m)
- Inlet Pressure: 15 to 150 psi (1.0 to 10.3 bar)
- Regulated Pressure: 40 psi (2.7 bar)
- Filtration: 200 mesh (75 micron) stainless steel mesh
- Temperature: Up to 150 °F (66 °C)
Models
- PRB-100: 1″ basket strainer with integrated 40 psi pressure regulator and 200 mesh (75 micron) stainless steel mesh
- PRB-QKCHK-100: 1″ bin strainer with integrated 40 psi pressure regulator and 200 mesh (75 micron) stainless steel mesh
Replacement filter screens
- QKCHK-100M: 100 mesh stainless steel screen, red
- QKCHK-200M: 200 mesh stainless steel mesh, white
Replacement cover
- QKCHKCAP (full lid with O-ring in body)
