Salt electrolysis w/ Domotics eXO iQ en solde

Description

eXO iQ SALINE CHLORINATORS

Salt Electrolysis with automatic, simple and effective disinfection.

Easy to install and use, saline chlorinators allow for complete pool treatment with minimal maintenance.

HOW DO THEY WORK?

Salt electrolysis is a simple principle  similar to the behavior of the sea and its ecosystem. The pool water is slightly salty at 4 g/l (9 times less than sea water).

With electrolysis,  through the cell, salt is transformed into gaseous chlorine, a powerful disinfectant that dissolves instantly in water. Chlorine gas destroys all microorganisms in the cell and provides the pool with a correct level of free chlorine . Active chlorine (HOCl) eliminated under the effect of solar UV rays is constantly renewed by the cell without the need for any intervention.

For the proper operation of the electrolysis,  the pH of the pool must be maintained between 7.2 and 7.6 . All Zodiac ®  saline chlorinators are equipped with  cells with high quality and long-lasting titanium electrodes , which guarantee peace of mind for the user.

Control all in one

Water quality control is centralized in a single interface: pH, chlorination, management of additional equipment (filtration pump, lighting…).

Tranquility

Thanks to its long-lasting electrode and its high-quality sensors, the eXO ® solution guarantees optimal water quality at all times. As proof of its reliability, the chlorinator has an unconditional guarantee of 3 years*.

Built-in Connectivity **

The iAquaLink TM application allows you to check remotely and in real time the quality control of your pool’s water and equipment*** from your tablet or smartphone.

*3 years unconditional warranty (equipment), 2 years (pH probe), 1 year (REDOX probe) **iAqualink application will be available during the 2019 season ***
Linked to the eXO ® solution

• All-in-one control: centralized water quality control (pH, chlorination, equipment…)
• Peace of mind: long-lasting electrodes, high-end probes
• Built-in connectivity: Wi-Fi connection to the iAquaLinkTM App +*

INCLUDES:

• command box
• Cell
• Kit of unions and reducers to be glued to the cell
• wall fixing kit
• Flow detector with installation kit
• Temperature probe with installation kit

Instruction manual

Model	eXO® iQ 10	eXO® iQ 18	eXO® iQ 22	eXO® iQ 35
Volume of treated water	40 m³	70 m³	100 m³	150 m³
chlorine production	10 g/h	18 g/h	22 g/h	35 g/h
output amperage	2.8 A	3.6 A	5.0 A	7.2 A

pH Link and Dual Link modules compatible with the eXo system:

• Integrated all-in-one regulation and disinfection solution
• Automatic regulation.
• Easy and accurate measurement (POD Kit)

Includes:

• pH probe
• ACL probe (Redox – Chlorine) (Dual Link model only)
• Buffer solutions for probes
• Drill
• piping kit
• POD kit (to install probes and sensors.

Generalities:

• Calibration: Semi-automatic 2 points pH 4 and pH 7 & Redox 470mV (buffer solutions provided)
• Setpoint: Factory setting: pH = 7.2 / Redox = 700 mV
• Safety: Overdose Safety, Low Values, Sensor Disconnected, Sensor Broken (pH Link)

Spare Parts
