Description
With unrivaled performance from 25′ to 50′, Rain Bird’s 5000 Series rotors are ideal for residential, light commercial and commercial applications. Combining the industry’s unique three-blade self-cleaning seal with remarkable Rain Curtain™ nozzles, the 5000 Series rotors give you the even coverage and long-lasting reliability that the best contractors demand.
- Exclusive Three Blade Self-Cleaning Seal
- Industry Leading Rain Curtain Nozzles
- Options for All Applications
Features
– Larger self-cleaning seal prevents leakage and protects internal parts from debris. – Rain Curtain™ nozzles provide even distribution across the entire range, including large wind-resistant droplets, and gentle oncoming watering, resulting in greener turf with less water. – A history of proven performance and reliability tested on millions of installations. – Self-cleaning irrigation sector adjustment port that prevents debris accumulation.
Specifications
Working range
- Precipitation rate: 0.20 to 1.5 in/h (5 to 37 mm/h)
- Radius: 25 to 50 ft (7.6 to 15.2 m)
- The radius can be reduced by up to 25% with the radius reduction screw
- Pressure: 25-65 psi (1.7 to 4.5 bar)
- Flow rate: 0.73 to 9, 63 gpm (4.2 to 36.6 l/m)
Specifications
- Inf thread entry 3/4″ NPT eiror female
- Full circle adjustment with return and 40° – 360° part circle adjustment
- 360° full circle fit only
Dimensions
- Height of elevation: Shrubs; 4″ (10.2 cm); 6″ (15.2 cm); 12″ (30.5 cm)
- Overall Body Height: Shrubs: 7 3/4″ (19.7 cm) 4″: 7 3/8″ (18.5 cm); 6″: 9 5/8″ (24.5 cm); 12″: 16 7/8″ (42.9 cm)
- Diameter of exposed surface: 1 5/8″ (4.1 cm)
