Description
Table electric – magneto protection (1.6 to 10A) contactor, scheduling clock 24. 3 positions: Auto / 0 / Manual. 16A 230v. protected and controlled output for underwater projector. The power to the cabinet can only be single phase (P + W + T) .
Electrical Box Types
|
Type |
Current Range |
Single-phase |
TRIFASICO |
| A | 1.6 A – 2.5A | 1 / 4CV | 3 / 4CV – 1CV |
| B | 2.5A – 4A | 1 / 2CV | 1,5CV – 2CV |
| C | 4A – 6.3A | 3 / 4CV – 1CV | 3CV |
| D | 6.3A – 10A | 1,5CV | 4CV |
DESCRIPTION:
IP-65 protection. Crystal transparent and lockable key. The driving circuit for all models is 230VAC depending on the model chosen, the power to the cabinets can be at least one of:
- single-phase 220 / 240V (P + N + T) 50Hz / 60Hz
- phase: 380 / 415V (3P + N + T) 50Hz / 60Hz
24H Clock control with programming steps every 1/4 / hour (ie, the clock is programmable in steps of 15 minutes). Connection for remote control of the pump (run / stop, …) for auxiliary equipment (cold detector, level control …). All products were provide with:
- Scheme electrical
- connection diagram
- User guide
- CE Certificate of conformity
- Board for each input and output cable.
- screws and dowels (4) for installation on the wall.
Depending on the current rating of the filtration pump should be selected type cabinet.
